| Form | Module Only |
|---|---|
| RoHS | RoHS |
| Type | Type 2, Type 4 |
| Features | Remote Signaling Contacts, Thermally Protected |
| Approval Agency | CE, CSA, UL |
| Number of Poles | 4 |
| Voltage - Protection Rating (VPR) | 1.2 kV |
| Current - Discharge (Max) (8/20µS) | 100 kA |
| Current - Discharge (Nom) (8/20µS) | 20 kA |
| Current - Short Circuit Rating (SCRR) | 100 kA |
| Voltage - Protection Level (VP) (2416) | 1.8 kV |
| Voltage - Continuous Operating (Max) (MCOV) | 420VAC |
