| Features | Status Flag |
|---|---|
| Interface | PWM |
| Load Type | Inductive |
| Technology | NMOS |
| Applications | DC Motors, General Purpose, Solenoids, Stepper Motors |
| Rds On (Typ) | 160 mOhm LS, 200 mOhm HS |
| Voltage - Load | 2.7 V ~ 10.8 V |
| Fault Protection | Current Limiting, Over Temperature, Short Circuit, UVLO |
| Voltage - Supply | 2.7 V ~ 10.8 V |
| Output Configuration | Half Bridge (4) |
| Current - Peak Output | 2A |
| Supplier Device Package | 16-QFN (4x4) |
| Current - Output / Channel | 1.5A |
